I3PC(b) 3 Inch Built-in MPPT Solar Centrifugal Pump for Borehole Water Supply

The I3PC(b) is a 3-inch solar submersible water pump with a built-in MPPT controller and centrifugal impeller design, developed for borehole water supply, irrigation, and other off-grid pumping applications.

Brand:
HUOPSOLAR
Model:
I3PC(b)
Pump Type:
Solar submersible pump (impeller type)
Outlet:
1.25/1.5 inches
Pump Diameter:
3 inches / 75 mm
Applications:
Domestic water supply, small-scale irrigation, drinking water
Certifications:
CE, ISO9001, GS, RoHS
Warranty:
2 years
Packaging Type:
Wooden crate
Category: Brand:

The I3PC(b) is a built-in MPPT solar centrifugal pump designed to move clean water from boreholes and deep wells where access to grid electricity is limited or unavailable. Its submersible centrifugal design combines an impeller-based pump with a brushless DC motor and integrated solar control, making it suitable for drawing groundwater and delivering it to irrigation systems, storage points, and other water-use locations. The compact integrated configuration is particularly useful for remote pumping sites where a separate control setup is less convenient.

As a solar borehole pump and solar submersible water pump, the I3PC(b) is suitable for deep-well irrigation, domestic water supply, village and rural water systems, clean drinking water, garden watering, and drip irrigation. It can also be used as a solar agricultural water pump for farms and livestock watering applications. By using available groundwater for irrigation and water supply in areas with limited conventional power access, the I3PC(b) provides a practical pumping option for agricultural sites, rural communities, and other remote locations.

New wpDataTable

No. Item Rated Voltage Optimum input  voltage(DC) Rated Power Optimum input  Power(W) Max. Flow Max. Head Outlet Cable Controller Solar panel
Open circuit voltage (VOC)
A I3PC3.0-25-24-200B 24V 20-55V 200W 80-500W 3.0m³/h 25m 1.25 " 2m SSCO ＜80V
B I3PC3.0-35-24-300B 24V 20-55V 300W 80-500W 3.0m³/h 35m 1.25 " 2m SSCO ＜80V
C I3PC3.5-47-48-400B 48V 30-110V 400W 200-900W 3.5m³/h 47m 1.25 " 2m SSCO ＜150V
D I3PC3.5-80-72-600B 72V 50-170V 600W 300-1200W 3.5m³/h 80m 1.25 " 2m SSCO ＜200V
E I3PC3.5-95-96-750B 96V 60-220V 750W 400-1600W 3.5m³/h 95m 1.25 " 2m SSCO ＜250V
F I3PC3.8-123-110-1100B 110V 60-220V 1100W 400-1600W 3.8m³/h 123m 1.25 " 2m SSCO ＜250V
G I3PC3.8-155-110-1300B 110V 60-220V 1300W 600-1800W 3.8m³/h 155m 1.25 " 2m SSCO ＜250V
H I3PC3.8-180-110-1500B 110V 60-220V 1500W 600-1800W 3.8m³/h 180m 1.25 " 2m SSCO ＜250V
I I3PC5.2-45-48-500B 48V 30-110V 500W 200-900W 5.2m³/h 45m 1.5 " 2m SSCO ＜150V
J I3PC5.2-50-72-600B 72V 50-170V 600W 300-1200W 5.2m³/h 50m 1.5 " 2m SSCO ＜200V
K I3PC5.2-75-96-750B 96V 60-220V 750W 400-1600W 5.2m³/h 75m 1.5 " 2m SSCO ＜250V
L I3PC6-84-110-1100B 110V 60-220V 1100W 400-1600W 6.0m³/h 84m 1.5 " 2m SSCO ＜250V
M I3PC6-125-110-1500B 110V 60-220V 1500W 600-1800W 6.0m³/h 125m 1.5 " 2m SSCO ＜250V
N I3PC7.5-43-96-750B 96V 60-220V 750W 400-1600W 7.5m³/h 43m 1.5 " 2m SSCO ＜250V
O I3PC7.5-62-110-1100B 110V 60-220V 1100W 400-1600W 7.5m³/h 62m 1.5 " 2m SSCO ＜250V
P I3PC7.5-78-110-1500B 110V 60-220V 1500W 600-1800W 7.5m³/h 78m 1.5 " 2m SSCO ＜250V

Head(m) 25 23 20 18 15 10 8 5
Flow(m3/h) 0.1 0.4 0.7 1.3 2.1 2.5 2.8 3.1
Head(m) 35 27.33 25.59 22.23 17.64 12.54 5.91 2.64
Flow(m3/h) 0.05 0.58 1.02 1.51 2.01 2.54 3 3.15
Head(m) 47 34.88 30.8 26.72 20.19 11.52 5.7 2.54
Flow(m3/h) 0.05 0.51 1.03 1.55 2.02 2.56 3 3.53
Head(m) 80 65.48 59.46 52.32 41.4 29.16 13.86 2.44
Flow(m3/h) 0.05 0.51 1.07 1.5 2.04 2.55 3.04 3.35
Head(m) 95 75.68 70.98 61.09 48.44 36.51 18.45 2.64
Flow(m3/h) 0.05 0.51 1.05 1.52 2.06 2.55 3.04 3.51
Head(m) 123 108.42 102.6 95.87 92.3 82.92 76.39 65.88 56.81 47.12 35.39 22.53 3.05
Flow(m3/h) 0.05 0.32 0.6 0.92 1.21 1.53 1.81 2.11 2.41 3.73 3.06 3.38 3.68
Head(m) 154 144.42 133.61 130.14 117.19 100.67 85.16 67.01 49.05 24.78 3.15
Flow(m3/h) 0.05 0.45 0.82 1.22 1.6 2.03 2.41 2.87 3.2 3.65 3.86
Head(m) 178 165.13 158.5 143.4 122.19 100.97 76.19 45.69 5.91
Flow(m3/h) 0.05 0.53 1.02 1.5 2.07 2.55 3.02 3.53 4.03
Head(m) 49.97 49.36 46.61 43.04 39.77 36.2 32.02 27.43 21.62 16.11 9.89 4.38
Flow(m3/h) 0.17 0.55 1.02 1.51 2 2.54 3.01 3.53 4.06 4.54 5.04 5.34
Head(m) 73 59.66 54.36 50.18 45.28 41.1 37.12 29.78 22.94 12.95 2.24
Flow(m3/h) 0.05 0.54 1.05 1.58 2.03 2.58 3.07 3.58 4 4.52 5.24
Head(m) 82.92 81.9 79.35 76.9 73.43 68.84 63.84 55.79 45.59 33.24 14.58 6.52
Flow(m3/h) 0.53 1 1.53 2.03 2.53 3.09 3.5 4.04 4.55 5.02 5.54 5.8
Head(m) 123.62 119.74 109.95 101.58 92.3 82 73.94 61.91 50.07 34.67 7.95
Flow(m3/h) 0.53 1.05 1.53 2.01 2.5 3.01 3.5 4 4.51 5 5.7
Head(m) 40 35 30 25 20 15 10 5
Flow(m3/h) 2.5 3.3 4.2 4.8 5.4 5.9 6.5 7.3
Head(m) 61.09 60.58 59.97 59.15 57.83 56.09 53.95 51.4 47.01 43.14 37.63 31.71 23.76 9.17
Flow(m3/h) 0.53 1.03 1.53 2.02 2.52 3.03 3.54 4 4.52 5.03 5.53 6.05 6.54 7.25
Head(m) 79.25 79.04 78.94 77.1 75.47 70.27 64.86 57.83 51.09 46.5 39.36 31.1 20.7 8.56
Flow(m3/h) 0.48 1.01 2.09 2.53 3.07 3.56 4.01 4.57 5.09 5.55 6 6.52 7.08 7.58

● 1 x 3-inch DC solar centrifugal pump with a 2-meter cable
● 1 x Pump outlet connector
● 1 x Cable connector kit
● 1 x Waterproof splicing kit
