ZSGJ-ADHY AC/DC Solar Jet Surface Pump with MPPT Controller and Brushless DC Motor

The HUOPSOLAR ZSGJ-ADHY is an AC/DC solar surface water pump with a jet-type design, brushless DC motor, and hybrid MPPT controller for domestic water supply, drinking water, and small-area irrigation.

Brand:
HUOPSOLAR
Model:
ZSGJ-ADHY
Pump Type:
Solar-powered jet surface pump
Outlet/Inlet:
1″ x 1″, 1.5″ x 1.5″
Applications:
Domestic water supply, small-scale irrigation, drinking water
Certifications:
CE, ISO9001, GS, RoHS
Warranty:
2 years
Packaging:
Wooden crate
Motor:
DC brushless motor
Controller:
AC/DC hybrid MPPT controller
Controller Protection Rating:
IP65
Customization:
OEM supported
Minimum Order Quantity:
5 sets
Category: Brand:

The ZSGJ-ADHY uses a jet-type surface-pump design with an AC/DC solar power configuration. Its brushless DC motor is paired with an AC/DC hybrid MPPT controller, while the jet structure distinguishes the model from centrifugal and peripheral surface pumps in the same range. The pump is intended for domestic water supply, drinking water, and small-area irrigation.

The jet configuration gives the ZSGJ-ADHY a distinct role within HUOPSOLAR's AC/DC solar surface pump range. For projects that require a solar powered water pump with a surface installation and jet-type pumping structure, this model provides a configuration that can be evaluated according to the project's water source and operating requirements. OEM customization is also supported.

No. Item Rated Voltage Optimum input  voltage(DC) Rated Power Optimum input  Power(W) Max. Flow Max. Head Outlet Cable Controller Solar panel
Open circuit voltage (VOC)
A ZSGJ3.1-35-72-550-AD 72V 50-170V 550W 300-1200W 3.1m³/h 35m 1.0×1.0 " 1m SSCO ＜200V
B ZSGJ3.1-40-96-750-AD 96V 60-220V 750W 400-1600W 3.1m³/h 40m 1.0×1.0 " 1m SSCO ＜250V
C ZSGJ4.0-60-200-1500-AD 200V 120-300V 1500W 600-1800W 4.0m³/h 60m 1.5×1.5 " 1m SSCO ＜450V
D ZSGJ6.0-80-300-2200-AD 300V 80-400V 2200W 1200-2800W 6.0m³/h 80m 1.5×1.5 " 1m SSCO ＜450V

Head(m) 32 30 25 20 17 11 6 2 1
Flow(m3/h) 1.2 1.5 2.1 2.3 2.4 2.6 2.7 2.8 3
Head(m) 46 42 40 32 25 22 16 11 6 2 1
Flow(m3/h) 0.1 0.6 1.3 1.9 2.4 2.6 2.6 2.7 2.8 3 3
Head(m) 61 56 52 46 42 31 20 16 12 6 3
Flow(m3/h) 0 0.2 0.8 1.6 2.2 3.4 3.9 3.9 3.9 3.9 3.9

● 1 x DC solar water pump (including 1m cable)
● 1 x Pump controller with MPPT function
● 1 x Stainless steel float switch (water tank sensor)
● 1 x Pump outlet connector
● 1 x Cable connection kit
● 1 x Waterproof connection kit
